I.Overview

Karl Fischer Coulomb titration is the most reliable method to detect trace moisture for different substances, which was utilized successfully by trace moisture titrator. What’s important, this instrument is able to work more reliably and conveniently by using the most advanced control circuit and 32 bit embedded microcontroller processor as the master control core and utilizing embedded mini operating system. Character with fast analyzing speed, simple operation, high precision and strong automatism, the trace moisture titrator has been widely used in the industry of petroleum, chemical, power, railway, pesticide, medicine and environmental protection.

Instrument features：

●The 32-bit embedded microprocessor is used as the main control core to embed the mini operating system.

●0-400ma automatic detection, high precision, fast measurement speed, stable and reliable.

●The motherboard adopts high-quality SMT components with high integration, simple operation and long service life

●Contains 4 calculation formulas, and the measurement results are automatically converted to the required units and can be converted to each other.

●Color touch screen, full numeric keyboard, more concise operation, convenient and quick data calculation.

●With graph curve analysis to help analyze water content trend.

●Switching between Chinese and English at any time.

II.Technical parameters

Titration method：Coulometric titration（Coulomb analysis）

Display：Color LCD touch screen

Electrolytic current control：0～400mA automatic control

Measurement scope：1ug～200mg

Sensitive valve：0.1µg H2O

Accuracy：10µg～1000µg±3µg

More than 1mg but not greater than 0.3%

Printer：Miniature thermal printer

Power supply：220V±10%、50Hz

Power：＜ 40W

Ambient temperature：5～40℃

Ambient humidity：≤ 85%

External dimension：380×310×180

Weight：About 6kg
