Nominal Parameter

Parameter

Nominal parameter

AC current output

The real value of each phase output when six phase current output  0～30A    output precision   0.2 grade

The real value of each phase output when three phase current output    0～60A

The real value of six phase parallel current output         0～180A

The allowed real value when the phase current work long time        10A

The maximum output power of phase current           450VA

The maximum output power when six phase parallel current output      1000VA

The allowed working time when six phase parallel current maximum output    10s

Frequency range（fundamental wave）        0～1000Hz

Harmonic order          0～20

DC current output

Current output   0～±10A / phase       output precision   0.2 grade

The maximum load volatage output          20V

AC voltage output

The real value of phase voltage output  0～120V    output precision  0.2grade

The real value of line voltage output          0～240V

The output power of phase voltage/ line voltage         80VA / 100VA

Frequency range（fundamental wave）       0～1000Hz

Harmonic order           0～20

DC voltage output

The output amplitude of phase voltage  0～±160V   output precision  0.2 grade

The output amplitude of line voltage            0～±320V

The output power of phase voltage/ line voltage            70VA / 140VA

Input and output

8 channels input

Free contact   1～20mA，24V

Electric potential contacts  “0”：0 ～ +6V； “1”：+11 V ～ +250 V

4 channels output  DC：220 V／0.2 A；AC：220 V／0.5 A

Time measurment range

0.1ms ～ 9999s ，    measurement accuracy ＜0.1ms
