Output frequency: 50HZ

Strong super capacity, the instantaneous current can withstand three times the rated current

One-key shutdown function in case of failure, fast response, response time within 2ms

With over-current, over-temperature, short-circuit, overload and other multiple protection and alarm functions

High-precision frequency stabilization function, fast adjustment of voltage and frequency

The main components are all imported brands with reliable quality

Three-phase 200KVA variable frequency power supply technical parameters

model:

HZBP-200KVA

Output capacity (200KVA)

200

circuit mode

IGBT/SPWM PWM method

AC input

Phase

3 phase  (3Φ4W+G)

waveform

SINEWAVE

Voltage

380V±10%

Frequency fluctuation range

60HZ±10%

power factor

﹥ 0.8

AC output

Phase

3 phase  (3Φ4W+G)

waveform

SINE    WAVE

Voltage

380V

frequency

50HZ

Frequency Stability

≤0.01%

Maximum current

304A

performance

Power regulation rate

﹤ 1%

Load regulation rate

﹤ 1%

Waveform Distortion

﹤ 2%

efficiency

﹥ 85%

Reaction time

≤2ms

Crest factor

3：1

protective device

It has multiple protections such as overcurrent, overload, overheating, short circuit, etc.

Display

display interface

Digital LED display

Voltage

4 digits, digital voltmeter, 0.1V resolution

current

4 digits, digital ammeter, 0.1A resolution

power

4 Digit, Digital Wattmeter

frequency

4 digits, digital frequency meter

environment and others

cooling device

High-speed inverter fan cooling, forced cooling

Operating temperature

-10℃ to   50℃

Relative humidity

0~90% (non-condensed state)

Altitude

≤1500m

weight(KG) 1200

Dimensions (H*D*W) mm          1770*1500*1000

Note: 1 The above dimensions do not include foot input height

2 can be customized according to customer requirements

3 The company's product specifications are continuously developed and improved, and the specifications are subject to change without prior notice.
