Dimension

250mmx75mmx270mm (length * width * height)

Excitation source

High-power high-performance X-ray microtube

Target

5 available targets for ray tubes are: gold (Au), silver (Ag),

tungsten (W), tantalum (Ta), palladium (Pd)

Voltage

35KV-50KV voltage (changeable)

Filter

A variety of selectable filters, automatically adjusted according to different tested objects

Detector

High-resolution SI-PIN detector (optional SDD detector)

Detector refrigeration temperature

Peltier effect semiconductor refrigeration system

Standard film

316 external standard films/window protection cover (internal

plus version standard films available)

Power supply

2 lithium batteries (7.2v�0mAh)

Processor

High-performance ARM pulse processor

Operating system

Windows CE6.0

Data transmission

USB flash disc with two-way interface (32G)

Standard mode

K-MAX Alloy Plus 6.0

Data processing

32G large-capacity data storage card: ≥80,000 sets of data and spectrograms

Display screen

High-resolution TFT industrial-grade colored high-definition

touch screen . It is ergonomic, sturdy, dust-proof, and waterproof,

clearly visible under any light conditions

Outline design

The integrated designed body is sturdy, waterproof, dustproof,    antifreeze, shockproof, and can be used normally in harsh environments

Safe operation

“One key” detection, auto-lock, detection auto-stop functions. The X-ray

will automatically be turned off if there is no sample in front of the

detection window for 2 seconds. 3/2 of the shell of the device is covered

with a 6061 aluminum alloy frame design, with better X-ray blockage.

Detection report

Customized detection report available as per the customers' demands

Element analysis

Mercury, cadmium, lead, arsenic, copper, zinc, nickel, drill,

vanadium, chromium, manganese and other elements can be

detected at the same time. In addition, other elements can be

detected according to customers’ requirements.
