Product Features

1. The instrument can be used independently or connected to a PC for use

2.7-inch LCD display, high-speed thermal printer, human-machine dialogue full keyboard operation mode, intelligent work process

3. Using power electronic control technology to generate high current output, the output current has fast response speed, high accuracy, and continuous adjustability

4. Multiple high-precision sensors automatically switch current ranges and high-performance 24 bit AD acquisition chip

5. It has a power-off storage function and can store 1000 sets of test data

6. Automatically save setting data, and display the previous setting data after power failure and startup

7. Choose between the Ansecond Action Test Method and the Flow Non Action Test Method

When used online, it is possible to operate and control instruments, import test data, store test data, generate data reports, generate data curves, generate EXCEL reports, etc.

9. The instrument is equipped with overheat, overcurrent, and overvoltage protection functions

10. The instrument has strong anti-interference ability and strong electromagnetic compatibility performance

Technical indicators

1. Power input: 220V ± 10%, frequency: 50Hz ± 0.5 Hz;

2. Test current range: 0-500A;

3. Test current ripple coefficient: less than 5%;

4. Stability of output current: ≤ 0.5%;

5. Time recording: 0-9999S; minimum time resolution: 0.001S;

6. Environmental temperature: -20 ℃ to 50 ℃

7. Dimensions: 470mm (length) x 320mm (width) x 460mm (height);

8. Weight: 20kg
