Simple technical features or parameters

Through servo motor, air spring, closed-loop control software, automatic reset, automatic loading, automatic holding, automatic testing, automatic unloading, automatic measurement of wear scar diameter and taking pictures are realized, one-key operation, one-key data storage, fast test speed and error Very small, good repeatability, no pollution, no noise, high efficiency.

1

Test force

1.1

Axial test force working range

10～10000N

1.2

Relative error of test force indication

±1％

1.3

Automatically maintain the indication error when the test force is long

±1％F.S

2

Friction torque

2.1

Friction torque measuring range

0～13500N.mm

2.2

Relative error of friction torque indication

±3％

3

Spindle speed

3.1

Spindle frequency conversion speed regulation range

10～2000r/min

3.2

Spindle speed error

±5r/min

4

Oil tank stroke

＞45mm

5

Spindle bore taper

1：7

6

Testing machine heating system

6.1

Heater operating temperature range

Room temperature ～250℃

6.2

Temperature control accuracy

≤2℃

7

Testing Machine Spindle Control

7.1

Testing machine time display and control range

1～99999s or 1-99999min

7.2

Testing machine revolution display and control range

999999999

7.3

The maximum torque output of the main motor of the testing machine

2.3N.m

8

Amount of oil used in one test

About 10ml

9

Special standard steel ball diameter

Ф12.7

10

Dimensions of the testing machine (length × width × height mm)

About 1160×750×1640

11

Testing machine net weight

About 400kg

12

Testing machine rated power

5.5KW

Product

1

Host

1

2

Computer (LCD Monitor)

1

3

Printer

1

4

15J Wear Spot Measurement Microscope

1

Appendix

1

High temperature wear auxiliary oil box

1

2

Normal temperature friction pair oil box

1

3

Four-ball special steel ball

1

4

Oil slinger (high/low temperature)

1 for each

5

Spring collet

2

6

Torque wheel

1

Tool

1

Lifting screw

4

2

Anti-vibration horn

4

3

Medical Tweezers (Medium)

1

4

Medium waist plate

1

5

Oil tank wrench (high/low temperature)

1 for each

6

Tool

1

7

Collet chuck wrench

1

8

Collet hammer

1
